The Design of the Mass Measuring Instrument Using the Arduino Uno Load Cell with an LCD Display

In the world of engineering and science, accuracy in measurement is very important. Therefore, it has been designed and made a device that can weigh the mass of objects using the HX711 sensor (load cell). This tool serves to weigh the mass of objects efficiently by the method of hanging. Measuring devices or instruments are devices used to determine the value of a quantity or variable. In order to be reliable, a measuring instrument must have accuracy and accuracy. The quality of a measuring instrument can also be proven through a calibration process, which is a test to ensure that the tool can provide accurate results.

The Importance of Measuring Instruments

Measuring instruments play a crucial role in various fields, including industry, research, and laboratories. They are used to determine the value of a quantity or variable, and their accuracy is essential in obtaining reliable results. A measuring instrument must have accuracy and accuracy to be considered reliable. The quality of a measuring instrument can also be proven through a calibration process, which is a test to ensure that the tool can provide accurate results. In this article, we will discuss the design of a mass measuring instrument using the Arduino Uno load cell with an LCD display.

How the Tool Works

This tool works automatically by responding to the mass of objects detected by the load cell sensor. The data collected by the sensor is then processed using Arduino Uno. The results of this processing will be the output displayed on the LCD screen. This process not only provides convenience in reading results but also increases efficiency and speed in mass measurement. The tool uses the HX711 sensor, which is a load cell amplifier that can be used to measure weight and force.

Accuracy Analysis

One of the advantages of this tool is a very low error rate, which is 0.107%. This shows that this tool has high accuracy in measuring the mass of objects. This low error rate is important in applications in the fields of industry, research, and laboratories, where accurate results are needed. The accuracy of the tool is due to the use of the HX711 sensor, which is a high-accuracy load cell amplifier.

Benefits and Uses

This mass measuring device design has a variety of benefits. In the world of education, this tool can be used by students and researchers to develop their understanding of the concept of mass measurement and electronics. On the other hand, in the industry, this tool can be used to measure the weight of goods in real-time, assist in controlling quality and cost savings. The tool can also be used in various fields, including food processing, pharmaceuticals, and textiles.

The Role of Arduino Uno

Arduino Uno is a microcontroller board that is used to process the data collected by the load cell sensor. It is a popular choice for various applications, including robotics, automation, and measurement systems. The Arduino Uno board is used to read the data from the load cell sensor and display the results on the LCD screen.

The Use of LCD Display

The LCD display is used to display the results of the mass measurement. It is a convenient way to read the results, and it also increases efficiency and speed in mass measurement. The LCD display is a 16x2 display, which means it can display 16 characters on two lines.

With the Arduino Uno-based mass measuring device design that utilizes a load cell sensor, we not only get an efficient and accurate tool, but also open up opportunities for further innovation in measurement technology. This tool is expected to increase productivity and facilitate the measurement process in various fields. The use of LCD as an output display also adds to the practical value of this tool, making the measurement results easier to read and analyze. In conclusion, the design of the mass measuring instrument using the Arduino Uno load cell with an LCD display is a reliable and efficient tool that can be used in various fields.

There are several areas where this tool can be improved. One area is the use of a more accurate load cell sensor. Another area is the use of a more efficient processing algorithm to improve the speed of the tool. Additionally, the tool can be improved by adding more features, such as the ability to measure multiple parameters.

[1] Arduino Uno. (n.d.). Retrieved from https://www.arduino.cc/en/Main/ArduinoBoardUno
[2] HX711. (n.d.). Retrieved from https://www.sparkfun.com/products/13878
[3] LCD Display. (n.d.). Retrieved from https://www.sparkfun.com/products/9060

The following is a list of the materials used in this project:

Arduino Uno board
HX711 load cell amplifier
Load cell sensor
LCD display
Breadboard
Jumper wires
Power supply

The following is a list of the software used in this project:

Arduino IDE
HX711 library
