Setting up a VPN can seem daunting, but with pfSense, it's totally manageable! This guide will walk you through setting up an IPsec L2TP VPN on your pfSense firewall. We're going to break it down step by step, so even if you're not a networking guru, you'll be able to follow along. So, grab your coffee, and let's dive in!

Why Use IPsec L2TP VPN?

Before we jump into the how-to, let's quickly cover the why. An IPsec L2TP VPN provides a secure way to connect to your home or office network remotely. The main reason for using IPsec L2TP VPN is its compatibility. It works well with many devices, including smartphones, tablets, and computers, without needing extra software on the client side. IPsec handles the secure encryption of your data, while L2TP creates the tunnel. It's a solid combination for secure remote access. However, keep in mind that while L2TP/IPsec is widely supported, it might not be the most modern or fastest VPN protocol available. Protocols like WireGuard or OpenVPN can offer better performance and security in some cases, but L2TP/IPsec remains a viable option when compatibility is key. For many users, the ease of setup and broad compatibility make it a practical choice. If you're looking for a balance between security, compatibility, and ease of setup, IPsec L2TP on pfSense is a really great option. Plus, pfSense makes the configuration process pretty straightforward, as you'll see in the following sections.

Prerequisites

Before we get started, make sure you have the following:

  • A pfSense firewall already set up and running.
  • A static public IP address or a dynamic DNS service configured. This is crucial so that your VPN clients can always find your pfSense box. If your IP address changes frequently, a dynamic DNS service will automatically update the DNS record with your current IP.
  • A basic understanding of networking concepts like IP addresses, subnets, and routing.
  • A user account on your pfSense firewall for VPN access. This will be the account your remote users will use to connect to the VPN. Make sure this account has strong credentials!

These prerequisites are essential to ensure a smooth setup process. Without them, you might run into issues that can be frustrating to troubleshoot. So, double-check that you have everything in place before moving on to the configuration steps.

Step 1: Configure IPsec

First, we'll configure IPsec, which handles the encryption part of our VPN. This involves setting up a Phase 1 and Phase 2 configuration. Let's get to it!

  1. Navigate to VPN > IPsec > Tunnels: In the pfSense web interface, go to VPN, then IPsec, and then Tunnels. This is where you'll manage your IPsec connections.
  2. Add a new Phase 1: Click the "Add P1" button to create a new Phase 1 entry. Phase 1 is responsible for establishing the initial secure connection between the client and the pfSense firewall.
    • Key Exchange version: Set this to "IKEv1". While IKEv2 is generally preferred for its improved features, IKEv1 is often more compatible with L2TP.
    • Internet Protocol: Choose IPv4 or IPv6, depending on your network setup.
    • Interface: Select your WAN interface (the interface connected to the internet).
    • Remote Gateway: Set this to "Dial-up User". This tells pfSense that the remote end will be a dial-up client with a dynamic IP address.
    • Authentication Method: Select "Mutual PSK + XAuth". This is the standard authentication method for L2TP/IPsec.
    • Pre-Shared Key: Enter a strong, complex pre-shared key. This key will be used to authenticate the connection. Make sure to share this key securely with your VPN users. A strong PSK is critical for the security of your VPN.
    • Encryption Algorithms: Choose appropriate encryption algorithms like AES256-SHA256. These algorithms will be used to encrypt the data transmitted through the VPN tunnel. Make sure to select strong and modern algorithms for maximum security.
    • Lifetime: Set a reasonable lifetime, like 28800 seconds (8 hours). This specifies how long the Phase 1 security association will remain active before needing to be renegotiated.
  3. Add a new Phase 2: After saving the Phase 1 configuration, click the "Add P2" button to create a new Phase 2 entry. Phase 2 handles the actual encryption of the data transmitted through the VPN tunnel.
    • Mode: Set this to "Tunnel IPv4" or "Tunnel IPv6", depending on your network.
    • Local Network: Specify your local network. This is the network that VPN clients will be able to access. Typically, this will be your LAN subnet.
    • Remote Network: Set this to 0.0.0.0/0 to allow all remote networks. This means that clients can access any network through the VPN. If you need to restrict access, you can specify a more specific remote network.
    • Protocol: ESP
    • Encryption Algorithms: Choose appropriate encryption algorithms like AES256-SHA256. Make sure these algorithms match those used in Phase 1.
    • PFS Key Group: Select a Diffie-Hellman group, such as DH Group 14 (2048 bit). Perfect Forward Secrecy (PFS) ensures that if one key is compromised, past sessions remain secure.
    • Lifetime: Set a reasonable lifetime, like 3600 seconds (1 hour). This specifies how long the Phase 2 security association will remain active before needing to be renegotiated.

Step 2: Configure L2TP

Now, let's configure the L2TP server on pfSense. This will handle the L2TP part of the VPN connection.

  1. Navigate to VPN > L2TP: In the pfSense web interface, go to VPN, then L2TP. This is where you'll configure the L2TP server settings.
  2. Enable L2TP Server: Check the box to enable the L2TP server.
    • Server Address: Enter a private IP address for the L2TP server. This will be the gateway address for VPN clients. Choose an IP address that's within your LAN subnet but outside the DHCP range to avoid conflicts.
    • Tunnel Address Range: Specify a range of private IP addresses for VPN clients. This range should also be within your LAN subnet but outside the DHCP range and the server address. Make sure you have enough addresses for all your expected VPN clients.
    • Secret: Enter a strong secret. This secret is used for L2TP authentication. Keep this secret safe and share it securely with your VPN users.
    • Authentication Type: Choose PAP or CHAP. PAP is simpler but less secure. CHAP is more secure. For better security, CHAP is generally recommended.
    • Assign IP addresses: Assign L2TP users to a specific Pool of IPv4 addresses.
  3. Save the L2TP configuration.

Step 3: Configure Firewall Rules

Next, we need to create firewall rules to allow VPN traffic to pass through the pfSense firewall. Without these rules, VPN connections will be blocked.

  1. Navigate to Firewall > Rules > IPsec: Go to Firewall, then Rules, and then IPsec. This is where you'll add rules for IPsec traffic.
  2. Add a new rule:
    • Action: Set this to "Pass". This allows the traffic to pass through the firewall.
    • Interface: Select "IPsec". This rule applies to traffic coming in through the IPsec interface.
    • Protocol: Set this to "ESP". ESP (Encapsulating Security Payload) is the protocol used to encrypt the data transmitted through the IPsec tunnel.
    • Source: Set this to "any". This allows traffic from any source IP address.
    • Destination: Set this to "any". This allows traffic to any destination IP address.
    • Description: Enter a description for the rule, such as "Allow IPsec ESP traffic".
  3. Save the IPsec rule.
  4. Navigate to Firewall > Rules > L2TP: Go to Firewall, then Rules, and then L2TP. This is where you'll add rules for L2TP traffic.
  5. Add a new rule:
    • Action: Set this to "Pass".
    • Interface: Select "L2TP". This rule applies to traffic coming in through the L2TP interface.
    • Protocol: Set this to "UDP". L2TP uses UDP for transport.
    • Source: Set this to "L2TP clients". This will allow traffic from the range specified earlier.
    • Destination: Set this to "any".
    • Destination Port Range: Set this to "L2TP".
  6. Create a Firewall Rule on the WAN Interface:
    • Action: Set this to "Pass".
    • Interface: WAN.
    • Protocol: UDP.
    • Source: any.
    • Destination: WAN Address.
    • Destination Port Range: ISAKMP (500) and NAT-T (4500).

Step 4: Configure User Authentication

Now, we need to make sure our VPN users can authenticate. We'll use the local user database on pfSense for this.

  1. Navigate to System > User Manager: In the pfSense web interface, go to System, then User Manager. This is where you manage user accounts.
  2. Edit the user account: Find the user account you created earlier for VPN access and click the "Edit" button.
  3. Enable L2TP/IPsec authentication: Make sure the user has the correct privileges to connect via VPN.
  4. Save the user configuration.

Step 5: Configure Client Devices

Finally, you need to configure your client devices (e.g., laptops, smartphones) to connect to the VPN. The exact steps will vary depending on the operating system, but here's a general outline:

  1. Create a new VPN connection: On your device, create a new VPN connection. Select L2TP/IPsec as the VPN type.
  2. Enter the server address: Enter the public IP address or hostname of your pfSense firewall.
  3. Enter the pre-shared key: Enter the pre-shared key you configured in the IPsec settings on pfSense.
  4. Enter the username and password: Enter the username and password for the user account you created on pfSense.
  5. Enter the L2TP secret: Some devices might ask for the L2TP secret. Enter the secret you configured in the L2TP settings on pfSense.
  6. Save the VPN connection settings.
  7. Connect to the VPN: Try connecting to the VPN. If everything is configured correctly, you should be able to establish a VPN connection.

Troubleshooting

If you run into problems, here are a few things to check:

  • Firewall rules: Double-check that your firewall rules are configured correctly.
  • IPsec and L2TP settings: Verify that your IPsec and L2TP settings match on both the pfSense firewall and the client device.
  • Pre-shared key and secrets: Make sure you've entered the correct pre-shared key and L2TP secret on both the pfSense firewall and the client device.
  • User authentication: Verify that the user account is enabled and has the correct privileges.
  • Logs: Check the pfSense logs for any error messages.

Conclusion

And there you have it! Setting up an IPsec L2TP VPN on pfSense can seem a bit complex at first, but by following these steps, you can create a secure and reliable VPN connection for remote access to your network. Remember to always use strong passwords, pre-shared keys, and secrets to protect your VPN from unauthorized access. This comprehensive guide should give you a solid foundation for getting your VPN up and running smoothly. Good luck, and happy networking!
